These hinges can handle large side loads, making them ideal for large gates and gates with automation.
Bolts directly to concrete. 70mm diameter bearing surface. Allows for lubrication of the axial roll bearing.
Use with Comunello Upper Hinge 85PST-G for optimal performance.
Suits automated Swing gates
High quality thrust bearing
Thrust Bearing
A tapered bottom bearing allows for high side and vertical loads making it ideal for heavy swing gates and automated swing gates
Grease Nipple
Allows for easy lubrication of the part
Material
Steel
Coating
Zinc Plated
Unit Weight
(kg)
1.25
